TO-252 Package Power Transistor for Motor Driver & High Power Frequency Converter

TO-252 Package Power Transistor for Motor Driver & High Power Frequency Converter Back

PDF

Introduction Yangjie Technology has added a new model of power transistor to the TO-252 package.It is equipped with NPN and PNP chips respectively, forming complementary transistor pairs. In terms of electrical parameters, this power transistor has a maximum IC current of 8A and is designed with low voltage resistance. It can be used in circuits such as electric drives and high-power frequency converters. The junction temperature and storage temperature of this product can reach -55~+150 ℃.

Features 1. MJD44H11B and MJD45H11B complement each other
2. Low collector emitter saturation voltage
3. Excellent switching speed
4. Plugin class encapsulation

SPECIFICATION

MJD44H11B MJD45H11B
