Micro-pattern Trenches IGBT for Servo Controller & Frequency Converter & Industrial Power Supply

Micro-pattern Trenches IGBT for Servo Controller & Frequency Converter & Industrial Power Supply Back

PDF

Introduction Yangjie Technology recently launched a new generation of TO-247 packaged 160A 650V discrete IGBT. The product adopts 1.6um micro-pattern trenches process platform, greatly improving power density ,having low conduction and switching loss.
It can be applied to low or medium frequency applications such as servo controllers, frequency converters, and industrial power supplies.

Features 1. Adopting 1.6um micro-pattern trenches process platform;
2. 650V breakdown voltage,Ic=50A@Tc=100℃ ；
3. Low conduction loss,low switching loss；
4. Strong short-circuit capacity

SPECIFICATION

DGW50N65CTL2A
