IGBT high frequency series C1 module

IGBT high frequency series C1 module Back

PDF

Introduction 1.IGBT high-frequency series products mainly have C1 (34mm) package shape;
2. Voltage level is 650V, current cover 100A~200A;
3. The products are mainly used in industrial welder, high-frequency power supply, UPS and other high-frequency applications;
4. The related series of products are completely pintopin replacement with the mainstream products in the market;
5.IGBT products are environment-friendly materials, in line with RoHS standards;

Features 1. Maximum junction temperature Tjmax=175℃;
2. Low turn-off loss, suitable for high frequency applications;
3. Continuous current diode with ultra-fast and soft recovery characteristics;
4. High short-circuit support current capacity (above 6US);
5. Use the DBC insulation heat dissipation baseboard;

SPECIFICATION
